NM400

Executive standard:GB/AS PER request
Thickness:3-150mm
Delivery Status:Q+T
HS code:72254099
Product description：NM400 Wear resisting steel adopt the first Word Pinyin NaiMo and its HBW value to name the grade; 400——Show the average brinell hardness of steel plate
INQUIRY

——NM400

NM400 Wear resisting steel adopt the first Word Pinyin NaiMo and its HBW value to name the grade;

400——Show the average brinell hardness of steel plate

1.NM400 belong to low alloy wear resistant steel

2.Named：NM400.

3.NM4000 its average HBW is 400

（International Stipulation Range of HBW：370～430）.

4.The Delivery Status NM400：quenched and Tempered .

5.Steel Plate size, Shape, Weight and allowable Deviation: should comply with the provisions of GB/T709.

6.Steel Surface Quality：conform to GB/T 3274;

7.The provisions of this standard and acceptance inspection items of the reinspection rules shall comply with the provisions of GB/T 17505.

8.Rolled Range：3-80mm（Other thickness two sides negotiate）

9.Chemical and mechanical Property：as following form

NM400 Chemical Property

GRADE

Chemical Property（Quality Percent）/%

Bta

AIs

CEV

≤

≥

≤

NM400

0.3

0.70

1.60

0.025

0.010

1.0

0.70

0.50

0.050

0.0005~0.006

0.010

0.55

Bta stands for Boron content。

NM400 Mechanical Property

GRADE

THICK

TENSIBLE STRENGTH

Rm MP a

YIELD STRENGTH

A₅₀%

—20℃ IMPACT TEST

AKv / J

HBW

NM400

3~80

≥1200

≥10

≥24

370~430

Tensile strength, elongation and impact energy as the special requirements of performance, such as customer did not indicate in the contract, the only guarantee the brinell hardness.
