NM400 high wear resistant steel

Steel Grade:NM400
Thickness:2mm-120mm
Executive standard :GB/EN/As per request
Delivery Status:Q+T
Product description：GENG JIN STEEL are professional high wear resistant steel suppliers,wear resistant steel plate is committed to domestic and imported steel NM360, NM400, NM450, NM500, NM550, NM600 ,NM650bulk sales, wa
INQUIRY

Abrasion Resistant Steel Plate NM400 (high wear resistant steel)

Key words:creusabro 4800 wear resistant steel plate,Hardox,hardox 400,ar500 plates,hardox 500,hardox 450,abrasion resistant steel,ar400 steel,wear plate,hardox steel,Hardox plate;

Size:Thickness 2-120mm Width :1000-4200mm Length :3000-12000mm

China	Raex	Creusabro	DILLIDUR	Durostat	HARDOX
NM400	RAEX400	Creusabro4800	400V	Durostat400	Hardox 400

Application :crushers, chutes, hoppers, crane booms, cutting edges, conveyor troughs, buckets, gear, sprockets, truck dump bodies, shovels , industrial trucks, railway wagon, bulldozers, excavators, concrete mixer drums, skrew conveyor, et

Abrasion Resistant Steel Plate NM400 Chemical Composition
Heat No.	Grade	C	Si	Mn	P	S	Ni+Mo+Cr	others	CEQ
S21301389	NM400	0.15	0.30	1.26	0.010	0.002	＜1.0	micro	0.41
S11301559	NM400	0.14	0.30	1.23	0.013	0.001	＜1.0	micro	0.49
S11205895	NM400	0.17	0.30	1.30	0.008	0.003	＜1.0	micro	0.55

Abrasion Resistant Steel Plate NM400 Machenical Property


Standard		Grade	Thick. / mm	Rm / MPa		A50/ %	Impact T/ ℃	KV2 / J	Hardness /HBW
GB/T 24186-2009		NM400	≤80	≥1200		≥10	--20	≥24	370~430
Plate No.	Heat No.	Grade	Thick. / mm	Re / MPa	Rm / MPa	A50/ %	Impact T/ ℃	KV2 / J	Hardness /HBW
Q3312192010	S21301389	NM400	6	1170	1283	13.5	-20	38/27/33	415
T1711154090	S11301559	NM400	32	1133	1332	16.5	-20	83/93/71	390
Q2C04092010	S11205895	NM400	60	1218	1305	18	-20	52/46/47	414
