Home > NM Wear plate

  • NM360
  • NM360
  • NM360
NM360NM360NM360

NM360

  • Executive standard:GB/AS PER request
  • Thickness:3-150mm
  • Delivery Status:Q+T
  • HS code:72254099
  • Product description:NM360 Wear resisting steel adopt the first Word Pinyin NaiMo and its HBW value to name the grade; 360——Show the average brinell hardness of steel plate.
  • INQUIRY

< Engineering Machinery with High Strength Wear Resistant Steel Plates >  ——NM360

NM360 Wear resisting steel adopt the first Word Pinyin NaiMo and its HBW value to name the grade; 360——Show the average brinell hardness of steel plate


1.NM360 belong to low alloy wear resistant steel

2.Named:NM360。

3.NM360 its average HBW is 360

(International Stipulation Range of HBW:330~390)。

4.The Delivery Status NM360:quenched and Tempered 。

5.Steel Plate size, Shape, Weight and allowable Deviation: should comply with the provisions of GB/T709.

6.Steel Surface Quality:conform to GB/T 3274;

7.The provisions of this standard and acceptance inspection items of the reinspection rules shall comply with the provisions of GB/T 17505.

8.Rolled Range:3-80mm(Other thickness two sides negotiate)

9.Chemical and mechanical Property:as following Table


NM360 Chemical Property

GRADE

Chemical PropertyQuality Percent/%

C

Si

Mn

P

S

Cr

Ni

Mo

Ti

Bta

AIs

CEV

NM360

0.25

0.70

1.60

0.025

0.015

0.80

0.50

0.50

0.050

0.0005~0.006

0.010

0.48

Bta stands for Boron content

NM360 mechanical Property

GRADE

THICK

mm

TENSIBLE STRENGTH

Rm MP a

YIELD STRENGTH

A50 %

—20℃ IMPACT TEST

AKv / J

HBW

NM360

3~80

≥1100

≥12

≥24

330~390

Tensile strength, elongation and impact energy as the special requirements of performance, such as customer did not indicate in the contract, the only guarantee the brinell hardness.


For more details ,please feel free to contact with us !

Business mail:wearsteelplate@foxmail.com

Whatsapp:+8618539970286


PREVIOUS:SA516GR55 NEXT:NM400
