Home > WNM wear plates

  • WNM650 high hardness abrasion resistant steel sheet
  • WNM650 high hardness abrasion resistant steel sheet
  • WNM650 high hardness abrasion resistant steel sheet
WNM650 high hardness abrasion resistant steel sheetWNM650 high hardness abrasion resistant steel sheetWNM650 high hardness abrasion resistant steel sheet

WNM650 high hardness abrasion resistant steel sheet

  • Steel Grade:WNM650
  • Thickness:8MM-150MM
  • Executive standard :WYJ
  • Delivery Status:Q+T
  • Product description:Abrasion resistant plate WNM650 ,its average hardness is 650 HBW ,its tensile strength is more than 1450 Mpa and its Yield strength is more than 1650 Mpa ;Thickness range we offer is from 8 mm to 150
  • INQUIRY

Abrasion resistant plate WNM650

Key Wrods:high wear resistant steel plate ,steel wear,wear resistant plate,abrasion resistant plate,high wear resistant steel

Wear resistant steel plate Comparison Table

WNM

RAEX

Creusabro

XRA

DILLIDUR

Durostat

Hardox

WNM650

-

-

-

-

-

-

Abrasion resistant plate WNM650

Chemical Composition and Mechanical property Refer to the following

Chemical Composition

steel plate

C

Si

Mn

P

S

Cr

Ni

Thickness

%

%

%

%

%

%

%

8-150mm

0.40-0.50

0.20-0.80

0.40-1.60

0.010-0.020

0.005-0.010

0.80-1.50

0.002-0.60

Hardness

620-680HB

Mechanical Properties

10mm thickness steel plate typical value

Yield Strength

Tensile Strength

Elongation

Re

Rm

A5

Mpa

Mpa

%

>1500

>1750

3

Impact Toughness

10mm thickness steel plate typical value

Test

Impact test

Temperature

Charpy-V Longitudinal

ºC

J

-20

6



Application: Wear resistant strip ,chute ,sieve plate ,cutting edge and etc.
