WNM450 high wear resistant steel plate

  • Steel Grade:WNM450
  • Thickness:8MM-150MM
  • Executive standard :Mill Standard
  • Delivery Status:Q+T
  • Product description:GENG JIN STEEL high wear resistant steel plate WNM450 ,its average hardness is 450 HBW ,its tensile strength is more than 1300 Mpa and its Yield strength is more than 1150 Mpa ;Thickness range we offe
  • INQUIRY

High wear resistant steel plate WNM450

Key Wrods:high wear resistant steel plate ,steel wear,wear resistant plate,abrasion resistant plate,high wear resistant steel

Wear resistant steel plate Comparison Table

NM

Hardox

XAR

DILLIDUR

Durostat

NM450

Hardox 450

XAR 450

450V

Durostat450

High wear resistant steel plate WNM450

Chemical Composition and Mechanical property Refer to the following

Chemical Composition

steel plate

C

Si

Mn

P

S

Cr

Ni

Thickness

%

%

%

%

%

%

%

2-120mm

0.20-0.26

0.75-0.95

1.60-1.80

0.015-0.020

0.005-0.010

0.01-0.60

0.001-0.04

Hardness

420-480HB

Mechanical Properties

10mm thickness steel plate typical value

Yield Strength

Tensile Strength

Elongation

Re

Rm

A5

Mpa

Mpa

%

>1150

>1300

10

Impact Toughness

10mm thickness steel plate typical value

Test

Impact test

Temperature

Charpy-V Longitudinal

ºC

J

-20

30

Application: Sieve plate ,wear resistant liner ,feeding hopper ,conveyor ,scraper conveyor ,dump truck ,screw conveyor and etc.
