SA517 Gr.B Nuclear Power Steel Plates
- Thickness：5-300mm
- delivery status:
- executive Standard :ASME SA-517/SA-517M-2010
- Trade term :FOB OR CFR
- Product description：The steel can be used to manufacture mechanical module safety supports for nuclear power plant with high strength, excellent plasticity and welding
The steel can be used to manufacture mechanical module safety supports for nuclear power plant with high strength, excellent plasticity and welding
Grade:SA517Gr.B、SA517Gr.F
Executive standard :ASME SA-517/SA-517M-2010
Product Specification. 5～300mm×1500～4100×Lmm；
Chemical Composition
/Heat Composition, %
|
Grade |
C |
Mn |
P |
S |
Si |
Ni |
Cr |
Mo |
B |
V |
Ti |
Cu |
|
SA517Gr.B |
≤0.20 |
≤1.00 |
≤0.035 |
≤0.035 |
0.15～0.30 |
/ |
≤0.65 |
≤0.25 |
≤0.005 |
0.03～0.08 |
0.01～0.03 |
/ |
|
SA517Gr.F |
≤0.20 |
≤1.00 |
≤0.035 |
≤0.035 |
0.15～0.35 |
≤1.00 |
≤0.65 |
≤0.60 |
≤0.006 |
0.03～0.08 |
/ |
0.15～0.50 |
Mechanical Property
Mechanical Property
|
Thickness |
ReL，MPa |
Rm，MPa |
A50，% |
reduction of area ,% |
Impact of the expansion
|
|
|
Rectangular
|
Circular
|
|||||
|
≤65 |
≥690 |
795～930 |
≥16 |
≥35 |
≥45 |
≥0.38 |
|
65～150 |
≥620 |
725～930 |
≥14 |
/ |
≥45 |
|
Delivery Condition：quenching+tempering
