SA387GR11CL2 ASME/ASTM pressure vessel steel plate thickness 5mm-300mm
- Executive standard:ASME/ASTM
- Thickness:5mm-300mm
- Delivery Condition:Nornalsing +Tempering
- HS CODE:72254099
- Product description：ASME/ASTM SA387GR11CL2 chromium molybdenum alloy steel plate intended primarily for welded boiler and pressure vessels designed of elevated temperature service.
ASME/ASTM SA387GR11CL2 is a chromium molybdenum alloy steel plate intended primarily for welded boiler and pressure vessels designed of elevated temperature service.
ASTM A387 Grade 11Class2 Specification：
Thickness: 5MM - 300MM Width: 1500mm - 4050mm Length: 3000mm - 15000mm
Chemical composition :
| Grade |
C |
Si |
Mn |
P |
S |
Cr |
Mo |
Cu |
| SA387GR11CL2 |
≤0.15 |
≤0.10 |
0.30～0.60 |
≤0.010 |
≤0.010 |
2.00～2.50 |
0.90～1.10 |
≤0.20 |
Mechanical Property :
| Grade |
Yield Strength Rel,MPa |
Yield Strength
Rm,MPa |
Elongation A，% |
Z，% |
-30℃ Impact energy ,J
|
bend 180°,d=3a |
High tensile Rp0.2 |
| SA387GR11CL2 |
310～620 |
515～690 |
≥19 |
≥45 |
≥54 |
well |
ASME |
Delivery Condition: normalizing+ tempering
Lead time: stock plates within 3 days ;order production within 3 months
Payment terms:TT or LC
