  • NM500 corrosion resistant steel plate/Sheet
  • NM500 corrosion resistant steel plate/Sheet
  • NM500 corrosion resistant steel plate/Sheet
NM500 corrosion resistant steel plate/SheetNM500 corrosion resistant steel plate/SheetNM500 corrosion resistant steel plate/Sheet

NM500 corrosion resistant steel plate/Sheet

  • Steel Grade:NM500
  • Thickness:2mm-120mm
  • Executive standard :GB/EN/As per request
  • Delivery Status:Q+T
  • Product description:Our wear resistant steel grade commit to domestic NM360, NM400, NM450, NM500, NM550, NM600 ,NM650bulk sales, warehouse, cutting and distribution.
  • INQUIRY

Abrasion Resistant Steel Plate NM500

Key words:abrasion resistant steel plate,ar500 steel plate,Hardox,hardox 400,ar500 plates,hardox 500,hardox 450,abrasion resistant steel,ar400 steel,wear plate,hardox steel,Hardox plate,ar500 steel sheet,stainless steel plate,ar500 steel;

NM RAEX Creusabro XRA DILLIDUR Durostat Hardox
NM500 RAEX500 Creusabro8000
XAR 500 500V Durostat 500
Hardox500

Size:Thickness 2-100mm Width :1000-4200mm  Length :3000-12000mm

Application:crushers, screens, chutes, hoppers, crane booms, cutting edges, conveyor, buckets, gears, sprockets, etc.

Abrasion Resistant Steel Plate NM500 Chemical Composition

Heat No.

Grade

C

Si

Mn

P

S

Ni+Mo+Cr

others

CEQ

S21301389

NM500

0.29

0.31

0.99

0.011

0.003

2.5

micro

0.71

S11301559

NM500

0.28

0.32

0.97

0.003

0.003

2.5

micro

0.71


Abrasion Resistant Steel Plate NM500 Mechanical Properties

Standard

Grade

Thick.

/ mm

Rm

/ MPa

A50/ %

Impact T/

KV2 / J

Hardness /HBW

GB/T 24186-2009

NM500

≤80

≥1200

≥10

--20

≥24

470~530

Plate No.

Heat No.

Grade

Thick. / mm

Re

/ MPa

Rm

/ MPa

A50/ %

Impact T/

KV2 / J

Hardness /HBW

T3111011010

S21300161

NM500

21

1355

1665

9.5

-20

47/53/46

499

Q3331271010

S21300160

NM500

51

1573

1665

13.5

-20

42/44/56

499
