Home > NM Wear plate

  • NM450 Abrasion resistant steel plate/Sheet
  • NM450 Abrasion resistant steel plate/Sheet
  • NM450 Abrasion resistant steel plate/Sheet
NM450 Abrasion resistant steel plate/SheetNM450 Abrasion resistant steel plate/SheetNM450 Abrasion resistant steel plate/Sheet

NM450 Abrasion resistant steel plate/Sheet

  • Steel Grade:NM450
  • Thickness:2mm-100mm
  • Executive standard :GB/EN/As per request
  • Delivery Status:Q+T
  • Product description:Our wear resistant steel grade commit to domestic steel NM360, NM400, NM450, NM500, NM550, NM600 ,NM650bulk sales, warehouse, cutting and distribution.
  • INQUIRY

Abrasion Resistant Steel Plate NM450

Key words:Hardox 450,abrasion resistant steel,wear plate,hardox steel,Hardox plate,anti abrasive steel,abrasive wear resistant steel,steel abrasive strips,Abrasion-Resistant Steel creusabro 4800, wear resistant steel plate;

NM Hardox XAR DILLIDUR Durostat
NM450 Hardox 450 XAR 450 450V Durostat450

Size:Thickness 2-120mm Width :1000-4200mm  Length :3000-12000mm

Application :crushers, chutes, hoppers, crane booms, cutting edges, conveyor troughs, buckets, gear, sprockets, truck dump bodies, shovels , industrial trucks, railway wagon, bulldozers, excavators, concrete mixer drums, skrew conveyor, etc.

Abrasion Resistant Steel Plate NM450 Chemical Composition

Heat No.

Grade

C

Si

Mn

P

S

Ni+Mo+Cr

others

CEQ

S21301389

NM450

0.17

0.31

1.26

0.008

0.002

1.0

micro

0.41

S21103228

NM450

0.20

0.30

1.23

0.012

0.003

1.6

micro

0.63











Abrasion Resistant Steel Plate NM450 Mechanical Properties

Standard

Grade

Thick.

/ mm

Rm

/ MPa

A50/ %

Impact T/

KV2 / J

Hardness /HBW

GB/T 24186-2009

NM450

≤80

≥1200

≥10

--20

≥24

370~430

Plate No.

Heat No.

Grade

Thick. / mm

Re

/ MPa

Rm

/ MPa

A50/ %

Impact T/

KV2 / J

Hardness /HBW

Q3108233020

S11205894

NM450

10

1170

1390

13

-20

83/77/77

452

T1711154090

S21103228

NM450

40

1340

1510

12

-20

57/74/57

461
