High Chromium Wear Plate

Steel Grade:CCO wear plate
Thickness:12+4
Executive standard :Mill Standard
Delivery Status:Mill standard
Product description：Wear resistance:Our test shows that the wear resistance plate is 20 times higher than low carbon steel and 8 times than heat treated steel.Chemical property:C: 3.5-5.5% Cr: 27%-40% wear resistant
INQUIRY

Features & Benefits

Cost effective solution when compared to traditional abrasion-resistant steels Chromium Carbid layers web

Recommended for resistance to wear by abrasion, fretting, cavitation, and particle erosion in high temperature applications (up to 1100°F).

Ideal for mild to moderate impact abrasion resistance.
Low maintenance cost and easy installation.
The overlay surface of CCO plate will consist of a series of beads with numerous
hairline cracks in them. These properly spaced crosscheck cracks are a natural
phenomenon and are beneficial to the material. The cracks propagate through the overlay and end at the fusion line.

Application Specifications

Cutting – Plasma burning, air arc, abrasive saw or water jet.
Welding – Our CCO overlay plate can be joined by welding the substrate to substrate using 309 weld wire/rod.
Bending – Using a press brake, forming should be perpendicular to the weld pass direction.Plate rolling should be performed in the directions of the overlay beads.

Technical Specifications & Chemical CompositionChromium Carbid_Chemical Composition
