Armox 500 armor plate armopro 500 ar500

thickness：3-25mm
delivery status:hot rolled
Executive standard :GB/ASME/ASTM
Trade term :FOB OR CFR
Product description：We has produced the protective steel of FD family with tensile strength 900MPa-2000MPa and of ArmaPro family with brinell hardness 440-630. With perfect bulletproof performance, cold forming and weldi
INQUIRY

We has produced the protective steel of FD family with tensile strength 900MPa-2000MPa and of ArmaPro family with brinell hardness 440-630. With perfect bulletproof performance, cold forming and welding property, Armor plate of Lianyuan steel can be widely used in some fields, such as private bulletproof vehicles, bank armored vehicles, armored personnel carriers, training range and anti-terrorist vehicles. Hot rolled LG900FD of us successfully passed the authentication of the Ministry of Public Security, which began to be used in armored cash carriers; Heat-treated armor plate of ArmaPro500 and 550 have successfully passed the inspection of China Academy of Ordnance Equipment and met the test requirements of NATO.

Steel grades	Stretching direction	Yield strength MPa (Typical value)	Tensile strength MPa (Typical value)	Elongation A% (Typical value)	Brinell hardness HBW (Typical value)	Dimension available
LG900FD	Transverse	≥800 (900)	≥900 (1000)	≥12(17)	270-330 (300)	2-8×1000-2000
ArmaPro440	Transverse	≥1000 (1300)	≥1250 (1500)	≥9(13)	410-470 (440)	3.0-25.0×1000-2000
ArmaPro500	Transverse	≥1250 (1450)	≥1450 (1750)	≥8(10)	470-530(500)	3.0-25.0×1000-2000
ArmaPro550	Transverse	≥1350 (1650)	≥1650 (1950)	≥8(10)	520-580 (550)	3.0-25.0×1000-2000
ArmaPro600	Transverse	≥1450 (1750)	≥1750 (2150)	≥7(10)	570-630 (600)	3.0-25.0×1000-2000
ArmaProAce	Transverse	-	≥2000 (2200)	≥6(8)	≥630	3.0-25.0×1000-2000

Protective grade

Steel grade	thicknes mm	Protection standards	Gun	Projectile	Striking velocity m/s	Shooting distance m	Class
LG900FD	2.85	GA 164-2005	Type 79 Submachine Gun	Type 51 7.62mm Pistol cartridge	490-515	5/10/15	A/B
ArmaPro 440	5	GJB 1496A-2000	Type 53 7.62mm speed gun	Type 53 7.62mm Steel core bullet	828	160
ArmaPro 440	6	GJB 1496A-2000	Type 53 7.62mm speed gun	Type 53 7.62mm Steel core bullet	828	120
ArmaPro 440	8	GJB 1496A-2000	Type 53 7.62mm speed gun	Type 53 7.62mmWO-109C Armor Piercing Incendiary	808	100 法线角
ArmaPro 440	10	GJB 1496A-2000	Type 53 7.62mm speed gun	Type 53 7.62mmWO-109C Armor Piercing Incendiary	808	100 法线角
ArmaPro 440	12	GJB 1496A-2000	Type 53 7.62mm speed gun	Type 53 7.62mmWO-109C Armor Piercing Incendiary	808	100 法线角
ArmaPro 500	2.5	GA 164-2005	Type 79 Submachine Gun	Type 51 7.62mm Pistol cartridge	490-515	5/10/15	A/B
ArmaPro 500	4	GA 164-2005	Type 56 7.62mm Submachine gun	Type 51 7.62mm Pistol cartridge	710-735	10/15/30	C
ArmaPro 500	4.2	EN 1522	Ballistic gun	7.62×39mm MSC cartridge	710-730	10	FB4+
ArmaPro 500	4.6	GJB 59.18-1988	Type 53 7.62mm speed gun	Type 53 7.62mm Steel core bullet	820-835	10/15/30
ArmaPro 500	6.5	EN 1522	AUG5.56mm Automatic Rifle	7.62×39mm MSC cartridge	940-960	10	FB5
ArmaPro 500	6.2	STANAG 4569	M14 7.62mm Automatic Rifle	NATO 7.62 rifle cartridge	830	15
ArmaPro 500	8.2	STANAG 4569	M14 7.62mm Automatic Rifle	NATO 7.62 rifle cartridge	830	10
ArmaPro 500	10	STANAG 4569	M16 5.56mm Automatic Rifle	M193 5.56mm normal bullet	995	10
ArmaPro 500	12	GJB 1496A-2000	Type 53 7.62mm speed gun	Type 53 7.62mmWO-109C Armor Piercing Incendiary	800-815	100
ArmaPro 550	5	GA 423-2015	Type 85 7.62mm Sniper Rifle	Type 53 7.62mm Steel core bullet	830	10
ArmaPro 550	5	GA 423-2015	Type 85 7.62mm Sniper Rifle	Type 53 7.62mm Steel core bullet	830	15	6
ArmaPro 550	6.2	EN 1522	Ballistic gun	7.62×51mm NATO cartridge	710-730	10	FB6
ArmaPro 550	8	STANAG 4569	M16 5.56mmAutomatic Rifle	5.56mm normal bullet	937	15	1
ArmaPro 550	11	GJB 1496A-2000	Type 53 7.62mm speed gun	Type 53 7.62mmWO-109C Armor Piercing Incendiary	800-815	100
ArmaPro 600	4.5	GJB 59.18-1988	Type 53 7.62mm speed gun	Type 53 7.62mm Steel core bullet	820-835	10/15/30
ArmaPro 600	6.5	STANAG 4569	AUG5.56mm Automatic Rifle	SS109 5.56 rifle cartridge	950	10
ArmaPro 600	6.5	STANAG 4569	M16 5.56mm Automatic Rifle	SS109 5.56 rifle cartridge	950	30	1
ArmaPro 600	6.5	STANAG 4569	M16 5.56mm Automatic Rifle	M193 5.56mm normal bullet	995	30
ArmaPro 600	6.5	STANAG 4569	M14 7.62mm Automatic Rifle	NATO 7.62 rifle cartridge	830	10	1
ArmaPro 600	6.5	STANAG 4569	M14 7.62mm Automatic Rifle	NATO 7.62 rifle cartridge	830	30	1
ArmaPro 600	10	GJB 1496A-2000	Type 53 7.62mm speed gun	Type 53 7.62mmWO-109C Armor Piercing Incendiary	800-815	100
ArmaPro 600	12	GJB 1496A-2000	Type 53 7.62mm speed gun	Type 53 7.62mmWO-109C Armor Piercing Incendiary	800-815	100
